Product News

Winstar introduce 5.0 inch IPS panel with PCAP touch screen
29 Nov 2017
Winstar 5.0 inch IPS display with PCAP touch screen
WF50DTYA3MNG10 is a 5 inch IPS TFT display with an optical bonded PCAP touch screen. It supports MIPI (Mobile Industry Processor Interface) and DSI (Display Serial Interface). The 720 x1280 resolution IPS panel has the advantage of wider viewing angle of 80 degrees in all directions.
Winstar introduce miniature Portrait mode TFT display
29 Nov 2017
Winstar 1.77 inch Portrait mode TFT display
The WF18FTLAADNN0 is a full colour, portrait mode 128x160 TFT-LCD display module with a diagonal size of 1.77 inch.  More below:
NEW LVDS 7" Portrait Mode IPS TFT from Winstar Displays
27 Oct 2017
7 inch Portrait format IPS TFT Panel with LVDS interface
The WF70WTYAULNN0 from Winstar Display is a 7 inch IPS TFT module with HD 800x1280 resolution. This 7 inch module has an onboard driver to support an LVDS interface and has a typical display brightness of 450 nits. It is designed for use in Portriat mode with a 9:16 aspect ration and has an Anti Glare finish.
NEW 5.0" HDMI TFT ideal for Raspberry Pi applications.
27 Oct 2017
5 inch TFT Module ideal for Raspberry Pi applications
The Winstar WF50BTIFGDHGX is a 5 inch HDMI TFT-LCD module with Projected Capacitive Touch Panel (PCAP). It has WVGA resolution of 800x480 dots and is supplied with a control board carrying a HDMI interface and a 40-pin GPIO connector. The display module is designed for easy integration into "Raspberry Pi" projects.
3.97" IPS-LCD TFT with MIPI interface from Winstar
26 Oct 2017
Winstar WF40BTYAQMNNO image
The new WF40BTYAQMNN0 from Winstar is a 3.97 inch IPS TFT-LCD module with resolution of 480x800 pixels.This TFT-LCD features an IPS panel which has the advantage of a wider viewing angle of Left:80/ Right:80/ Up:80/Down:80 degree (typical) and a wider operating temperature range.
Winstar Introduce 3.5" IPS TFT Module
25 Oct 2017
Designed for handheld instrument applications which require wider viewing angles,the Winstar WF35UTYAIDNN0 is a 3.5 inch IPS TFT Panel with 320x480 resolution.
Winstar introduce new 2.4" & 2.8" TFT LCD Modules
21 Jun 2017
The latest WF24E & WF28E are small format TFT displays from Winstar are both full colour 240 x 320 RGB TFT LCD modules with diagonal sizes of 2.4 & 2.8 inch respectively.Both modules have a built in ILI9341V driver IC which supports 8/ 16bit 8080-series Parallel MCU Interface.  The WF24H model has module dimension of 42.72 x 60.26 mm and Active area size of 36.72 x 48.96 mm whilst the WF28E models dimensions are 50.0 x 69.2 mm and Active area size of 43.2 x 57.6 mm. Logic supply voltage range from 2.5V to 3.3V. Display brightness is measured at up to 500 cd/m2 making either device ideal for handheld and bench top instruments.  Both display are designed for portrait mode applications however if you would like to use it as landscape mode, please contact with us for technical support.
NEW Waterproof Medical & Industrial Keyboards
11 May 2017
Waterproof Keyboards for Medical use - Diamond HMI
DiamondHMI's new range of waterproof and easy to clean keyboards are designed for medical products, clean industrial applications including food processing, semiconductor manufacturing and laboratories, POS systems and public area data input and control.
Diamond HMI Introduce Small Footprint OLED Displays
12 Jan 2017
Small Footprint OLED Displays
Diamond HMI have introduced the latest Winstar small outline, passive matrix OLED displays. The range comprises 4 sizes of module, 0.49, 0.66”, 0.71”& 0.84. Each size is available in White or Sky Blue characters.Application include Wearable devices, medical devices and consumer goods.
Diamond HMI sign new agreement with ALGRA AG of Switzerland
26 Jan 2015
Diamond HMI have signed and agreement with ALGRA AG of Switzerland to act as both their Exclusive Agent and Distributor for the UK market. ALGRA are world leaders in the design and Manufacture of Piezo Keypads using their patented DYNAPIC® and DYNASIM® technology.
Winstar P Series TFT's
24 Nov 2014
Winstar P Series TFT
Following on from the success of Winstars excellent Q Series TFT's which saw the introduction of 3.5 / 4.3 / 5.7 / 7.0 / 8.0 and 10.2" TFT Modules with built in SSD1963 Controllers we are excited to announce the launch of the new P Series.These latest panels utilise the powerful Raio RA8875 controller which offers a standardised 36 pin interface supporting 8 or 16 bit Parallel options and includes onboard flash memory. There is even a built in LED backlight driver providing brightness adjustment and thus eliminating the need to design this on your board.Resistive and Capacitive Touch Screens versions are available with the Touch Screen Driver being onboard meaning the I2C read / write protocol can be input directly from the 36 pin connector which further simplifies your PCB design.

Company News

Diamond HMI at EDS 2016
15 Aug 2016

Diamond HMI will be exhibiting their range of HMI solutions at EDS 2016.

Support Diamond Electronics at the Manchester Run 2015
23 Mar 2015

Diamond Electronics are once again entering a team in the Manchester Run 2015 sponsored by Morrison’s PLC.

Diamond HMI will be at SMEE 2015
8 Jan 2015
SMEE 2015

Diamond HMI will again be at Southern Manufacturing and Electronics 2015 which this year is a three day event running from the the 10th to the 12th of February.

Located at FIVE complex in Farnborough the event introduces visitors to a wide range of suppliers to the technology manufacturing sector. Diamond HMI will be showing a new range of custom Piezo keypad from ALGRA Switzerland. From January 2015 Diamond has been appointed UK exclusive distributor of ALGRA Piezo products and we look forward to introducing stand visitors to new concepts in keypad design.

Diamond to attend Electronics Design Show 2014
22 Jun 2014
Electronics Design Show 2014

Diamond will be attending the Electronics Design Show which is being held on the 22nd and 23rd of October at the Jaguar Exhibition Hall, Ricoh Arena, Coventry.

Manchester 10K - Six Of The Best For Diamond
23 Apr 2014

The Diamond Electronics Group have put together a team to compete in the Manchester Great Run for the sixth year running.  This year we are supporting Marie Curie Cancer Care and The Robert Jones and Agnes Hunt Orthopaedic Hospital for children.

Diamond HMI attend SMEE 2014
12 Aug 2013

For the fifth consecutive year Diamond HMI will be showcasing its products at Southern manufacturing 2014 which is taking place at the FIVE complex in Farnborough Hampshire on the 12th and 13th of Feruary 2014

HMI Blog

As consumers we have all become comfortable with the touch screen on other hand held gadgets and even our laptop monitors. Where a tactile response of a key is deemed to be required industrial designer often propose complex 3D solutions such as Silicone rubber keypads. So what is the future of membrane keypad technology?

Clearly there are still some major plus points to using a membrane primarily it is has the cheapest cost of entry to producing an integrated custom keypad solution for any electronic product. For many business’s this can be the overriding factor for consideration and in for applications a well-designed membrane keyboard can work very well.

The ability to include string printed graphics from a full pallet of colour can help a product stand out from the crowd. Top layers can be changed easily and at little cost whenever a rebranding is required.

Although key travel varies only slightly it is possible to tune the tactile response for membrane keypads incorporating either poly-domes or metal domes. The use of embossed switch areas and selective gloss coating can add to the visual effect.

Finally Including SMD LED’s within the keyboard sandwich can reduce a products manufacturing costs and produce a better overall finish.

Membrane keypads clearly still have their applications in HMI design with their simple structure and easy integration. Find out more by talking to our membrane design team who will demonstrate many new ideas in the membrane keyboard market
